McGill CFE 1 1/8 S CAMROL® Cylindrical Inch Cam Follower - Stud Mount Roller - Screwdriver Slot - Sealed ***FACTORY ORDER ONLY***
- Regular price
- €0,00
- Sale price
- €0,00
- Regular price
-
Free shipping on orders over $100
Use code at checkout.
Orders placed before 3:00pm (Est) ship same day
Lightning-fast shipping, guaranteed.
Key Features
- Stud type cam follower
- Cylindrical outside diameter
- Needle rolling elements
- Slot hole
- LUBRI-DISC® seal
- Eccentric configuration
Description
McGill® bearings are recognized worldwide for their precision, reliability, and performance in demanding industrial applications. With decades of engineering expertise, McGill offers a complete line of cam followers, needle bearings, spherical roller bearings, and other specialty products designed to handle high loads, reduce friction, and extend service life.
Built with premium materials and advanced manufacturing processes, McGill bearings deliver consistent operation even in harsh environments such as oil & gas, food processing, power transmission, and heavy machinery. Their innovative designs provide superior load distribution, misalignment compensation, and resistance to wear, helping reduce downtime and maintenance costs.
Whether for OEM applications or critical replacement needs, McGill bearings are trusted by engineers and maintenance professionals across industries to ensure smooth, efficient, and long-lasting performance.
Specifications
Dimensions
| Threads | 7/16-20 |
| Roller Diameter (in) | 1.125 in |
| Bushing Diameter (in) | 0.625 in |
| Stud Diameter (in) | 0.4375 in |
| Lubrication Fitting Size (in) | 0.1875 in |
| Stud Length (in) | 1 in |
| Roller Width (in) | 0.625 in |
| Eccentricity (in) | 0.03 in |
| Minimum Thread Length (in) | 0.5 in |
| Bushing Length (in) | 0.5 in |
| Lubrication Fitting Size (mm) | 0.1875 mm |
| Weight (kg) | 0.11 kg |
Technical Specifications
| Dynamic Radial Rating | 2,225 |
| Adjustment | Eccentric Bushing |
| Sealing | Sealed |
| Limiting Speed | 3,400 |
| Rolling Element | Needle Roller - Full Complement |
| Series | Inch CAMROL® |
| Hex/Slot | Screwdriver Slot |
| O.D. Configuration | Cylindrical |
| Material | Bearing Steel, Black Oxide Finish |
| Stud Type | Standard Stud with Eccentric Bushing |
| Dynamic Load Rating (lb) | 2,225 lb |
| Tolerance Class | P0 Equivalent |
| Static Load Rating | 3,060 |
| Platform | CAMROL® |
| Roller Shape | Cylindrical |
| Lubrication Hole Location | Stud side |
| Ability to Relubricate | Yes |
| Clamping Torque (in-lbf) | 250 lbs |
General Specifications
| UPC | 726166033958 |
| Weight | 0.25 LB |
| Packaged Length | 1.50 IN |
| Packaged Width | 1.75 IN |
| Packaged Height | 2.18 IN |
