Description

Number of Rows	1
Cage Material	Steel
Static Load Capacity	13100 lbs
Manufacturer Catalog Number	MR 20 SS
Closure Type	Sealed - Both Sides
Compatible Inner Ring	MI 16
Flanges	No Flange
Operating Temperature Range	-20 to 250 °F
Outside Diameter	1.7500 in
Fillet Radius	0.0400 in
Lubrication Hole Type	Lubrication groove and hole
Seal Material	Rubber Lip
Weight	0.32 lbs
Needle Bearing Type	Machined Race Needle Roller without Inner Ring Bearings
Overall Width	1.2500 in
Series	Cagerol Bearing
Bore Diameter	1.2500 in
Bearing Material	52100 Bearing Steel
Dynamic Load Capacity	9020 lbs
Maximum RPM	3050 RPM
Precision Rating	RBEC-1
CAD Drawing	Click here
Standards Met	ABMA, ISO
Manufacturer UPC Number	726166065881
