Description
SPECIFICATIONS
| Bore Diameter | 17 mm |
|---|---|
| Outside Diameter | 40 mm |
| Overall Width | 0.6875 in |
| Contact Angle | 25 ° |
| Row Type & Fill Slot | Double-Row Non-Fill Slot |
| Internal Clearance | C3 |
| Closure Type | Double Seal |
| Radial Dynamic Load Capacity | 1490 kgf |
| Radial Static Load Capacity | 920 kgf |
| Operating Temperature Range | Maximum of +250 °F |
| Cage Material | Synthetic Resin |
| Outer Ring Width | 17.5 mm |
Description
SPECIFICATIONS
| Bore Diameter | 17 mm |
|---|---|
| Outside Diameter | 40 mm |
| Overall Width | 0.6875 in |
| Contact Angle | 25 ° |
| Row Type & Fill Slot | Double-Row Non-Fill Slot |
| Internal Clearance | C3 |
| Closure Type | Double Seal |
| Radial Dynamic Load Capacity | 1490 kgf |
| Radial Static Load Capacity | 920 kgf |
| Operating Temperature Range | Maximum of +250 °F |
| Cage Material | Synthetic Resin |
| Outer Ring Width | 17.5 mm |
NSK
by
NSK
NSK 5203-2RSTNC3 Double Row Angular Contact Bearing
