Description
| Specification | Details |
|---|---|
| Bore Diameter | 1.575 in |
| Outside Diameter | 3.15 in |
| Width | 0.906 in |
| Basic Dynamic Load Rating | 22,144 lbf |
| Basic Static Load Rating | 20,570 lbf |
| Reference Speed | 8,000 r/min |
| Limiting Speed | 11,000 r/min |
| SKF Performance Class | SKF Explorer |
| Number of Rows | 2 |
| Locating Feature, Bearing Outer Ring | Without |
| Bore Type | Cylindrical |
| Cage | Sheet metal |
| Radial Internal Clearance | C3 |
| Tolerance Class for Dimensions | Normal |
| Tolerance Class for Run-Out | P5 |
| Sealing | Without |
| Lubricant | None |
| Relubrication Feature | With |
| Product Net Weight | 1.149 lb |
| eClass Code | 23-05-09-11 |
| UNSPSC Code | 31171510 |
