Description
Lightweight, Fast and Compact
Suitable for A3 refrigerants, The NRDDF recovery unit is designed and tested to UL 121201, CSA C22.2 No. 213-17 and IEC 60079-7 Standards. It features a Brushless DC Motor making it lightweight and much more efficient, a large backlit display, twin cylinder design with 2-row oversized condenser, oil free compressor and self-purging functionality. The NRDDF recovery unit is suitable for all commonly used refrigerants making it the ideal recovery unit!
NRDDF Model Specifications
| Specification | Details |
|---|---|
| Model | NRDDF |
| Refrigerant Type |
Category III: R-12, R-134a, R-401C, R-500, R-1234yf, R-600a Category IV: R-22, R-401A, R-401B, R-402B, R-407C, R-407D, R-408A, R-409A, R-411A, R-411B, R-412A, R-502, R-509, R-290 Category V: R-32, R-402A, R-404A, R-407A, R-407B, R-410A, R-454B, R-507 |
| Prohibited Refrigerants | RE170, R702, R1150, R429A, R432A, R435A, R510A |
| Power Supply | 115V / 60Hz |
| Motor | 1 HP |
| Max Current Draw | 10 A |
| Compressor | Oil-less, Air-cooled, Piston style |
| Automatic Safety Shut-Off | 558 psi / 38.5 bar |
| UL Verified Recovery Rate (lbs/min, kg/min) |
R-410A: Direct Vapor: 0.75 (0.34), Direct Liquid: 14.44 (6.55), Push/Pull Liquid: 18.41 (8.35) R-22: Direct Vapor: 0.64 (0.29), Direct Liquid: 11.11 (5.04), Push/Pull Liquid: 17.04 (7.73) R-134a: Direct Vapor: 0.57 (0.26), Direct Liquid: 7.85 (3.56), Push/Pull Liquid: 12.81 (5.81) |
| Dimensions (inches) | 14.5 × 9.9 × 11.7 |
| Weight | 24.3 lbs |
| Warranty | 1 Year* *For recovering only HVAC/R refrigerants from sealed HVAC/R systems. Warranty voided if used for any other purposes. |
⚠ WARNING: This product operates under high pressure. Follow all safety guidelines regarding refrigerant handling, including wearing Personal Protective Equipment such as safety glasses and gloves.
