Whittet-Higgins PWT-15 Precision Lockwasher – 2.973in bore, 4.093in OD

Authorized Retailer Made in the USA Top Rated

Whittet Higgins PW-01 Lockwasher Precision

Brand: Whittet-Higgins

Regular price: $6.29
Sale price: $6.29
Regular price

Shipping calculated at checkout.

Product variants:

Quantity:

1000 in Stock Now

Free shipping on orders over $100

Use code at checkout.

FREESHIP

Orders placed before 3:00pm (Est) ship same day

Lightning-fast shipping, guaranteed.

Quantity Discount Table

Quantity Discounti
Quantity	Discount
1 Unit	No Discount
20-49 Units	5%
50-99 Units	8%
100-199 Units	15%
200-499 Units	18%
500+ Units	25%

Need Help?

Call us 1 (248) 429-9073

Oxford, Michigan

Need tax exemption or quantity pricing? We offer special rates for businesses and bulk orders.

FREE SHIPPING

All Orders Over $100 Ship Free Ground

HASSLE-FREE RETURNS

Free 90-Day Returns No Questions Asked

Full policy

EXPERT SUPPORT

Support Staff Available By Phone, Web Chat, Or Email.

PRICE MATCH

Simply provide proof of a competitor's advertised price on the same item, and we'll match it.

Full policy

Whittet-Higgins

Whittet-Higgins specializes in high-quality bearing retention and shaft-locking products used in demanding industrial applications. Its core product range includes precision locknuts, lockwashers, adapter and withdrawal sleeves, shaft nuts, and related installation tools designed to securely position bearings and rotating components. The company offers both inch and metric options, including heavy-duty and corrosion-resistant designs for power transmission, machinery, and other industrial equipment.

Key Features

Carbon steel construction, made in the USA and RoHS compliant
Precision-ground parallel faces ensure assembly straightness to the threaded shaft
Provides accurate angular positioning with numerous locking positions
Prevents assembly loosening from vibration, shock, and torque
Matched with PW series locknuts and compatible with TAN series locknuts
No special tools required for installation
Effective on both soft and hardened shafts
Meets and exceeds ANSI/ABMA 8.2-1999 specification
Maximum operating temperature of 300°F

Description

The Whittet-Higgins PW-01 is a precision lockwasher in the PW series, manufactured from carbon steel for securing, locking, and retaining bearings and power transmission assemblies on threaded shafts. Its precision-ground parallel faces ensure assembly squareness and straightness to the shaft, while the washer provides accurate angular positioning across numerous locking positions to prevent loosening caused by vibration, shock, and torque.

Designed to be matched with PW series locknuts and compatible with TAN series locknuts, the PW-01 installs without special tools and performs effectively on both soft and hardened shafts. It meets and exceeds the requirements of ANSI/ABMA 8.2-1999, is rated for operation up to 300°F, and is made in the USA and RoHS compliant.

Specifications

PW-01

Specification	Value
Series	Whittet-Higgins PW Series
Bore Size	0.484 in (12.29 mm)
Outside Diameter	1.109 in (28.17 mm)
Face Diameter	0.734 in (18.64 mm)
Thickness	0.042 in (1.07 mm)
Material	Carbon Steel
Used With	PW series locknuts; also works with TAN series locknuts
Standard	ANSI/ABMA 8.2-1999
Weight (approx.)	0.006 lb (2.722 g)
Country of Origin	USA
