The GEARWRENCH family of torque wrenches & torque products offer the latest innovations in torque measurement. Included in the line are micrometer, tire shop, beam and electronic torque wrenches, as well as, torque multipliers. The micrometer wrenches are available in fixed head and flex head. The fixed head line offers wrenches in 1/4" to 3/4" drives. The flex head wrenches are available in 3/8" and 1/2" drives. The tire shop wrenches feature a rugged tire tread rubber cover on the head intended to specifically be used for checking wheel lug nuts and are available in 3/8" and 1/2" drives. The electronic torque wrenches ensure a more precise fastener torque level and are available in a 3/8" and 1/2" drives. The GEARWRENCH line of torque products allow the user to complete any job where accurate torque is required.

Features

36-tooth ratchet mechanism with a 10° swing arc allows you to turn fasteners in spaces other tools can't fit
Torque accuracy of +/- 3% CW between 20% and 100% of wrench capability
Twist locking collar provides a secure locking mechanism for consistent performance
Scale markings are highly visible and easy to read
Pliable, elastomer handle lets you grip comfortably, while oil and solvent resistance feature keeps your hands in place
Meets or exceeds ISO 6789 and ASME B107.300-2010 standards and specifications
1 year limited warranty; calibration accuracy warrantied for 90 days

Specifications

Prop 65	WARNING: This product contains or produces a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
ASME Specification	B107.300
Minimum Torque (Primary Scale)	100 ft/lb
Tether Ready	No
Maximum Torque (Primary Scale)	600 ft/lb
Minimum Torque (Alt Scale)	152.6 Nm
Maximum Torque (Alt Scale)	830.6 Nm
Torque Accuracy (20-100% of Full Range)	+/-3% Clockwise
Certified	No
Head Thickness Less Tang	0.37 in
Primary Scale Increments	2.5 ft/lb
Alt Scale Increments	3.4 Nm
Type	Micrometer
Knurled	Yes
Flexible	No
Overall Length	42.4 in
Packaging	Boxed
Weight (Catalog)	15.8 lb
Warranty	90 Days Calibration / 1 Year on Parts
Drive Tang Size	3/4 in
Tooth Count	36
Finish	Full Polish Chrome
Overall Height	2.6 in
UPC	099575005657
Included Storage	Blow Mold Case
Overall Width	2.6 in
Drive Type	Square
Material	Alloy Steel
