Description

Bore Diameter	1-1/4 in
Outside Diameter	1-1/2 in
Overall Width	1 in
Drawn Cup Type	Open Ends with Full Complement
Closure Type	Open
Operating Temperature Range	Maximum of +250 °F
Dynamic Load Capacity	8590 lbf
Static Load Capacity	20800 lbf
Cage Material	No Cage
Maximum RPM	3500 RPM
Precision Rating	Not Rated
Series	B
Lubrication Hole Type	No Hole
Standards Met	ANSI/ABMA 18.2, ASTM F2162
Compatible Inner Ring	IR-1616
Weight	0.12 lbs
