Description
Number of Rows | 1 |
---|---|
Cage Material | No retainer |
Static Load Capacity | 22400 lbs |
Manufacturer Catalog Number | RS 10 |
Closure Type | Shielded - Both Sides |
Flanges | No Flange |
Operating Temperature Range | -20 to 250 °F |
Outside Diameter | 2.0625 in |
Fillet Radius | 0.0313 in |
Lubrication Hole Type | Lubrication Groove & Hole |
Seal Material | Shield |
Weight | 0.54 lbs |
Needle Bearing Type | Machined Race Needle Roller with Inner Ring Bearings |
Overall Width | 1.0630 in |
Series | Multi-Rol Bearing |
Bore Diameter | 1.2500 in |
Bearing Material | 52100 Bearing Steel |
Dynamic Load Capacity | 6830 lbs |
Maximum RPM | 3300 rpm |
Precision Rating | RBEC-1 |
CAD Drawing | Click here |
Standards Met | ABMA, ISO |
Manufacturer UPC Number | 726166073275 |
Description
Number of Rows | 1 |
---|---|
Cage Material | No retainer |
Static Load Capacity | 22400 lbs |
Manufacturer Catalog Number | RS 10 |
Closure Type | Shielded - Both Sides |
Flanges | No Flange |
Operating Temperature Range | -20 to 250 °F |
Outside Diameter | 2.0625 in |
Fillet Radius | 0.0313 in |
Lubrication Hole Type | Lubrication Groove & Hole |
Seal Material | Shield |
Weight | 0.54 lbs |
Needle Bearing Type | Machined Race Needle Roller with Inner Ring Bearings |
Overall Width | 1.0630 in |
Series | Multi-Rol Bearing |
Bore Diameter | 1.2500 in |
Bearing Material | 52100 Bearing Steel |
Dynamic Load Capacity | 6830 lbs |
Maximum RPM | 3300 rpm |
Precision Rating | RBEC-1 |
CAD Drawing | Click here |
Standards Met | ABMA, ISO |
Manufacturer UPC Number | 726166073275 |
McGill
by
McGill
McGill RS10 Needle Roller Bearing
- Regular price
- $99.00
- Sale price
- $99.00
- Regular price
-
Out of stock
