McGill RS10 Needle Roller Bearing
Brand:
McGill
- Regular price
- $99.00
- Sale price
- $99.00
- Regular price
-
Shipping calculated at checkout.
Call 1 (248) 429-9073 for Availability
Orders placed before 3:00pm (Est) ship same day
Lightning-fast shipping, guaranteed.
Need Help?
Call us 1 (248) 429-9073
Description
| Number of Rows | 1 |
|---|---|
| Cage Material | No retainer |
| Static Load Capacity | 22400 lbs |
| Manufacturer Catalog Number | RS 10 |
| Closure Type | Shielded - Both Sides |
| Flanges | No Flange |
| Operating Temperature Range | -20 to 250 °F |
| Outside Diameter | 2.0625 in |
| Fillet Radius | 0.0313 in |
| Lubrication Hole Type | Lubrication Groove & Hole |
| Seal Material | Shield |
| Weight | 0.54 lbs |
| Needle Bearing Type | Machined Race Needle Roller with Inner Ring Bearings |
| Overall Width | 1.0630 in |
| Series | Multi-Rol Bearing |
| Bore Diameter | 1.2500 in |
| Bearing Material | 52100 Bearing Steel |
| Dynamic Load Capacity | 6830 lbs |
| Maximum RPM | 3300 rpm |
| Precision Rating | RBEC-1 |
| CAD Drawing | Click here |
| Standards Met | ABMA, ISO |
| Manufacturer UPC Number | 726166073275 |
