About
Description
Closure Type | Sealed - One Side |
---|---|
Operating Temperature Range | -30 to 300 °F |
Outside Diameter | 52 mm |
Lubrication Hole Type | Lubrication Groove & Hole |
Seal Type | Single Seal |
Internal Clearance | Normal |
Bore Type | Straight |
Outer Ring Width | 18 mm |
Bore Diameter | 25 mm |
Bearing Material | 52100 Bearing Steel |
CAD Drawing | Click here |
Manufacturer UPC Number | 726166001254 |
Cage Material | Steel |
Static Load Capacity | 7300 lbs |
Manufacturer Catalog Number | SB 22205 W33 S |
Maximum Operating Temperature | 300° F |
Maximum RPM Grease | 5000 rpm |
Fillet Radius | 0.0390 in |
Weight | 0.40 lbs |
Finish Coating | Uncoated |
Overall Width | 18 mm |
Series | 22200 |
Dynamic Load Capacity | 9000 lbs |
Maximum RPM | 10000 rpm |
Precision Rating | P0 | ISO 15-2008 |
Outer Ring Type | Not Split |
Description
Closure Type | Sealed - One Side |
---|---|
Operating Temperature Range | -30 to 300 °F |
Outside Diameter | 52 mm |
Lubrication Hole Type | Lubrication Groove & Hole |
Seal Type | Single Seal |
Internal Clearance | Normal |
Bore Type | Straight |
Outer Ring Width | 18 mm |
Bore Diameter | 25 mm |
Bearing Material | 52100 Bearing Steel |
CAD Drawing | Click here |
Manufacturer UPC Number | 726166001254 |
Cage Material | Steel |
Static Load Capacity | 7300 lbs |
Manufacturer Catalog Number | SB 22205 W33 S |
Maximum Operating Temperature | 300° F |
Maximum RPM Grease | 5000 rpm |
Fillet Radius | 0.0390 in |
Weight | 0.40 lbs |
Finish Coating | Uncoated |
Overall Width | 18 mm |
Series | 22200 |
Dynamic Load Capacity | 9000 lbs |
Maximum RPM | 10000 rpm |
Precision Rating | P0 | ISO 15-2008 |
Outer Ring Type | Not Split |
McGill
by
McGill
McGill SPHERE-ROL® SB 22205 W33 S Spherical Roller Bearing
- Regular price
- $135.00
- Sale price
- $135.00
- Regular price
-
1 in Stock Now
