Sealmaster PVR-2137 Mounted Cast Iron Flange Cartridge Ball Bearing Steel, Black Oxided - Setscrew Lock
- Regular price
- $1,514.00
- Sale price
- $1,514.00
- Regular price
-
Free shipping on orders over $100
Use code at checkout.
Orders placed before 3:00pm (Est) ship same day
Lightning-fast shipping, guaranteed.
FREE SHIPPING
All Orders Over $100 Ship Free Ground
HASSLE-FREE RETURNS
Free 90-Day Returns No Questions Asked
EXPERT SUPPORT
Support Staff Available By Phone, Web Chat, Or Email.
PRICE MATCH GUARANTEE
Simply provide proof of a competitor’s advertised price on the same item, and we’ll match it
Key Features
- Wide race and rollers and steel cage for high dynamic load ratings
- Race-mounted felt seal with flinger and misalignment sealing
- Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
- Powder coat epoxy cast iron housing
Description
Sealmaster® is a leading brand of mounted bearings known for durability, precision, and ease of installation. Engineered for demanding industrial applications, Sealmaster bearings are available in a wide range of styles including pillow blocks, flange units, and take-up housings, with options in ball, spherical, and tapered roller designs.
Sealmaster units feature rugged housings, advanced sealing systems, and multiple shaft locking options to deliver long service life and reliable performance, even in contaminated or high-load environments. Widely used in material handling, food and beverage, HVAC, agriculture, and heavy industry, Sealmaster bearings are trusted worldwide for reducing downtime and maintenance costs.
Specifications
Dimensions
| Bolt Size (in) | 7/16 in |
| Overall Width (in) | 6.13 in |
| Overall Length (in) | 6.13 in |
| Overall Height (in) | 2.03 in |
| Bore Diameter (in) | 1.9375 in |
| Foot Height (in) | 0.44 in |
| Pilot Diameter (in) | 4.25 in |
| Length Through Bore (in) | 2.029 in |
| Housing Outside Diameter (in) | 6.13 in |
| Bolt Circle (in) | 5.125 in |
Technical Specifications
| Rolling Element | Ball Bearing |
| Bore Shape | Straight |
| Pilot Configuration | Piloted |
| Housing Construction | One Piece |
| Outer Ring Land Profile | Standard |
| Misalignment Type | Static Only |
| Housing Color | Black |
| Cage Material | PPS - Polyphenylene Sulfide |
| Housing Type | Flange, Piloted |
| Seal Type | Single Lip Contact Seal |
| Housing Style | Flange Block |
| Ability to Relubricate | Yes |
| Inner Race Heat Treat Method | Zone-Hardened |
| Pilot Depth (in) | 0.44 in |
| Misalignment Capability | ±2.0° Misalignment - Static Only |
| Size Code | 2-115 |
| Bearing Insert Material | 52100 Bearing Steel |
| Vibration Frequency Outer Ring Defect | 0.0683 cps |
| Radial Clearance | Standard |
| Lubricant | Lithium Complex Grease With Synthetic Oil |
| Fixed vs. Expansion | Fixed |
| Max Operating Temperature (F) | 220 °F |
| Insert | 2-115 |
| Bearing Type | Standard Duty |
| Maximum Speed (RPM) | 325 rpm |
| Vibration Frequency Roller Spin | 0.0445 cps |
| Cage Type | Land Riding Retainer |
| End Cap Available | No |
| Inner Ring Outside Diameter (in) | 2.469 in |
| Grease Fitting Thread Size | 1/8 NPT |
| Dynamic Load Rating (lb) | 7,889 lb |
| Housing Material | Cast Iron |
| Vibration Frequency Fundamental Train | 0.0068 cps |
| Housing Coating | Powder Coated |
| Vibration Frequency Inner Ring Defect | 0.0984 cps |
| Shaft Locking Type | Set Screw |
| Static Load Rating (lb) | 5,216 lb |
| Bearing Insert Finish | Black Oxide |
General Specifications
| UPC | 662461311257 |
| Weight | 7.10 LB |
| Packaged Length | 6.75 IN |
| Packaged Width | 6.50 IN |
| Packaged Height | 2.44 IN |
| HTC | 8483.20.4040 |
| Country of Origin | United States of America |
