SKF 52228 Axial Deep Groove Ball Bearing - 120 mm ID, 200 mm OD, 81 mm Width
- d 120 mm
- D 200 mm
- B 81 mm
- Open (None)
- C0 - Normal
Genuine SKF product, SKF
- Regular price
- $2,395.68
- Sale price
- $2,395.68
- Regular price
-
Same-day shipping
Order by 3 PM ET for same-day shipping
Free shipping on orders over $100
Use code at checkout.
SKF 52228
$2,395.68
Why Apollo USA
Bearings from Apollo Industries, Oxford, Michigan
Apollo Industries supplies bearings, seals and maintenance tools to businesses across the US, with real people on the phone when you need a part matched.
-
Same-day shipping
Order by 3 PM EST for same-day shipping.
-
Free shipping over $100
All orders over $100 ship free by ground with code FREESHIP.
-
90-day returns
Hassle-free returns on unused items within 90 days.
-
Price match
Show us a competitor's advertised price on the same item and we will match it.
-
Expert support
Support staff available by phone, web chat or email.
-
Need tax exemption or quantity pricing?
We offer special rates for businesses and bulk orders.
Talk to a bearing specialist
2695 Lake George RdOxford, MI 48370
Overview
SKF 52228 Thrust bearing
Axial Deep Groove Ball Bearing
Axial Deep Groove Ball Bearings are versatile and widely used bearings. They can accommodate radial loads and, to a lesser extent, axial loads in both directions. Known for their low friction and quiet operation. Manufactured to precision tolerance class for demanding applications. Robust steel cage construction ensures durability. Suitable for use in a wide range of industrial applications where reliability and performance are essential.
Key features
- Designed for high axial loads in one direction
- Precision manufactured to exacting quality standards
Specifications
SKF 52228 dimensions & specifications
- Bearing type
- Thrust bearing
- Bore diameter d
- 120 mm (4.724 in)
- Outside diameter D
- 200 mm (7.874 in)
- Width B
- 81 mm (3.189 in)
- Seals / shields
- Open (None)
- Internal clearance
- C0 - Normal
- Weight
- 19.07 lb
- Brand
- SKF
- Part number
- 52228
- UPC / EAN
- 7316570179804
All specifications
Dimensions
| Bore Diameter | 120 mm |
| Outside Diameter | 200 mm |
| Width | 81 mm |
Properties
| Angular adjustment | Non-angle adjustable |
| Cage | Sheet steel cage |
| Material | Standard bearing steel |
| Operating direction | Double direction bearing |
| Product range | Axial deep groove ball bearing |
| Temperature range | -30 to +150 °C |
| Tolerance class | Tolerance class P0/PN2 / ABEC 1 |
Logistics
| Product Net Weight | 8.65 |
Cross reference
52228 cross reference & equivalents
Bearings from other brands with the same boundary dimensions. Check seals, clearance, cage and precision class before you order.
-
FAG
52228
Same size
-
Consolidated
52228
Same size
Reference data only. Verify specifications before you order.
Search more equivalents in the Apollo Bearing IndexTools & lubrication
Complete the job for your 52228
Mount it without damage and keep it lubricated. Tick what you need and add it with one click.
Part number decoded
What every part of 52228 means
- 522
- 522xx thrust ball, double direction (dimension series 22)
- 28
- Bore code 28 × 5 = 140 mm (ISO convention)
Catalogs & documents
SKF 52228 catalogs & documents
Official catalogs and data from the manufacturer. They open as PDFs in a new tab.
-
Catalog
SKF Rolling bearings catalogue (PUB BU/P1 17000) (opens in a new tab)
PDF · 23.0 MB · English
-
Catalog
SKF Explorer deep groove ball bearings (BU/P2 17453/2) (opens in a new tab)
PDF · 0.5 MB · English
-
Mounting
SKF Bearing maintenance handbook (10001/1) (opens in a new tab)
PDF · 14.2 MB · English
-
Guide
SKF Bearing damage and failure analysis (14219/3) (opens in a new tab)
PDF · 8.7 MB · English
-
Guide
SKF Bearing damage evaluation guide (07038/4) (opens in a new tab)
PDF · 0.9 MB · English
-
Technical
SKF Electrically insulated bearings (6160) (opens in a new tab)
PDF · 0.7 MB · English
-
Safety
Buy genuine SKF products (GC/S9 19135) (opens in a new tab)
PDF · 0.4 MB · English
About the brand
About SKF
Inventor of the self-aligning ball bearing and the spherical roller bearing.
SKF (AB Svenska Kullagerfabriken) was founded in Gothenburg, Sweden, on 16 February 1907, on one invention: the double-row self-aligning ball bearing of Sven Wingquist, a maintenance supervisor at a Gothenburg textile factory. The factory stood on clay, so the building moved, the line shafts fell out of alignment and the rigid ball bearings of the day overheated and failed. Wingquist's bearing let the shaft run out of line without shortening its service life.
SKF invented the spherical roller bearing in 1919 and launched the spherical roller thrust bearing in 1939, the CARB toroidal roller bearing in 1995 and SKF Explorer bearings in 1999. Explorer bearings have optimized internal designs and surfaces that reduce friction and heat and carry heavier loads, for a longer service life.
In 1926 an SKF subsidiary, AB Volvo, built a trial series of cars; the first Volvo rolled out in Gothenburg in 1927.
Genuine SKF product
Founded
1907
Headquarters
Gothenburg, Sweden
Employees (2025)
37,271
Present in
About 130 countries
Known for
- Self-aligning ball bearings
- Spherical roller bearings
- SKF Explorer bearings
- CARB toroidal roller bearings
- INSOCOAT and hybrid bearings
Disclaimer: Apollo Industries is not an authorized distributor, reseller, or representative of SKF. All SKF trademarks and product names are the property of their respective owners. We sell genuine SKF products purchased through independent channels.
FAQ
52228 questions & answers
What are the dimensions of the SKF 52228?
The SKF 52228 has a 120 mm bore (d), a 200 mm outside diameter (D) and a 81 mm width (B). In inches: 4.724 × 7.874 × 3.189 in.
What type of bearing is the 52228?
The SKF 52228 is a thrust bearing.
Is the 52228 sealed or shielded?
The SKF 52228 is an open bearing (Open (None)): it has no seals or shields.
What internal clearance does the 52228 have?
The SKF 52228 has C0 - Normal internal clearance.
What can I use instead of the SKF 52228?
Equivalents with the same boundary dimensions include FAG 52228, Consolidated 52228. Check the seals, internal clearance, cage and precision class before you order.
Is this a genuine SKF bearing?
Yes. Apollo Industries sells genuine SKF products, purchased through independent channels. Apollo is not an authorized distributor, reseller, or representative of SKF.
Do you ship the 52228 the same day?
In-stock orders placed by 3 PM EST ship the same day. All orders over $100 ship free by ground with code FREESHIP.
Can I get quantity pricing or buy tax-exempt?
Yes. Apollo offers special rates for businesses and bulk orders. Use Request a quote on this page or call (248) 429-9073.
