SKF NU220 ECP Cylindrical Roller Bearing - 100 mm ID, 180 mm OD, 34 mm Width

  • d 100 mm
  • D 180 mm
  • B 34 mm
Brand: SKF

Genuine SKF product, SKF

$774.63
$774.63
$903.24
Shipping calculated at checkout.
green lightning bolt icon for industrial tools and equipment
20 in Stock Now

Same-day shipping

Order by 3 PM ET for same-day shipping

Buying 20 or more, or need tax exemption?

Request a volume quote

Call Us

(248) 429-9073

Request a quote

Tell us the part number and quantity. We reply with pricing and lead time.

Why Apollo USA

Bearings from Apollo Industries, Oxford, Michigan

Apollo Industries supplies bearings, seals and maintenance tools to businesses across the US, with real people on the phone when you need a part matched.

  • Same-day shipping

    Order by 3 PM EST for same-day shipping.

  • Free shipping over $100

    All orders over $100 ship free by ground with code FREESHIP.

  • 90-day returns

    Hassle-free returns on unused items within 90 days.

  • Price match

    Show us a competitor's advertised price on the same item and we will match it.

  • Expert support

    Support staff available by phone, web chat or email.

  • Need tax exemption or quantity pricing?

    We offer special rates for businesses and bulk orders.

    Contact us

Map of Oxford, Michigan
Oxford, Michigan

Talk to a bearing specialist

(248) 429-9073

sales@apollousa.com

2695 Lake George Rd
Oxford, MI 48370
Request a quote Contact us

Overview

SKF NU220 ECP Cylindrical roller bearing

Cylindrical Roller Bearing

SKF cylindrical roller bearings carry heavy radial loads at high speeds. The line contact between rollers and raceways gives high radial load capacity and stiffness, making them ideal for gearboxes, electric motors and large industrial machinery.

Key features

  • High radial load capacity
  • Suitable for high speeds
  • High stiffness

Specifications

SKF NU220 ECP dimensions & specifications

Drawing of the SKF NU220 ECP, bore d 100 mm, outside diameter D 180 mm, width B 34 mm B 34 mm D 180 mm d 100 mm
Drawn to scale from the catalog dimensions.
Bearing type
Cylindrical roller bearing
Bore diameter d
100 mm (3.937 in)
Outside diameter D
180 mm (7.087 in)
Width B
34 mm (1.339 in)
Weight
7.47 lb
Brand
SKF
Part number
NU220 ECP also written NU220ECP
UPC / EAN
7316577054364

All specifications

Dimensions

Bore Diameter100 mm
Outside Diameter180 mm
Width34 mm

Properties

BoreCylindrical bore
CagePolyamide cage
ClearanceNormal radial clearance
Current insulationNo current insulation
DesignFloating bearing, inner ring removable on both sides
Outer ringWithout groove/lubrication holes
Roller rowsSingle row bearing
SealNone, open bearing
Temperature range-30 to +120 °C
Tolerance classDimensional accuracy P0/PN or ABEC 1, running accuracy P6 or
VersionExplorer
VersionImproved interior construction

Logistics

Product Net Weight3.389

Tools & lubrication

Complete the job for your NU220 ECP

Mount it without damage and keep it lubricated. Tick what you need and add it with one click.

Part number decoded

What every part of NU220 ECP means

NU
Outer ring with two flanges, inner ring without flanges
2
NU2xx cylindrical roller, light (dimension series 02)
20
Bore code 20 × 5 = 100 mm (ISO convention)
EC
Optimized internal geometry for higher load capacity (cylindrical roller)
P
Glass fibre reinforced polyamide (PA66) cage, injection moulded
Decode another part number

Catalogs & documents

SKF NU220 ECP catalogs & documents

Official catalogs and data from the manufacturer. They open as PDFs in a new tab.

About the brand

About SKF

Inventor of the self-aligning ball bearing and the spherical roller bearing.

SKF (AB Svenska Kullagerfabriken) was founded in Gothenburg, Sweden, on 16 February 1907, on one invention: the double-row self-aligning ball bearing of Sven Wingquist, a maintenance supervisor at a Gothenburg textile factory. The factory stood on clay, so the building moved, the line shafts fell out of alignment and the rigid ball bearings of the day overheated and failed. Wingquist's bearing let the shaft run out of line without shortening its service life.

SKF invented the spherical roller bearing in 1919 and launched the spherical roller thrust bearing in 1939, the CARB toroidal roller bearing in 1995 and SKF Explorer bearings in 1999. Explorer bearings have optimized internal designs and surfaces that reduce friction and heat and carry heavier loads, for a longer service life.

In 1926 an SKF subsidiary, AB Volvo, built a trial series of cars; the first Volvo rolled out in Gothenburg in 1927.

Genuine SKF product

Explore SKF bearingsShop all SKF

  • Founded

    1907

  • Headquarters

    Gothenburg, Sweden

  • Employees (2025)

    37,271

  • Present in

    About 130 countries

Known for

  • Self-aligning ball bearings
  • Spherical roller bearings
  • SKF Explorer bearings
  • CARB toroidal roller bearings
  • INSOCOAT and hybrid bearings
SKF website (opens in a new tab)

Disclaimer: Apollo Industries is not an authorized distributor, reseller, or representative of SKF. All SKF trademarks and product names are the property of their respective owners. We sell genuine SKF products purchased through independent channels.

Apollo USA Bearing Search Tool

Apollo USA Bearing Search Tool

Stop guessing what bearing you need. The Apollo Bearing Index has 98,500+ bearings across 100+ brands — paste FAG 22215-E1-XL-K-C4 and see what every letter means, or search by PN, dimensions, or the machine the bearing lives in (Haas, Mazak, DMG MORI, Caterpillar, Vestas, and 400+ more).

Learn More

FAQ

NU220 ECP questions & answers

What are the dimensions of the SKF NU220 ECP?

The SKF NU220 ECP has a 100 mm bore (d), a 180 mm outside diameter (D) and a 34 mm width (B). In inches: 3.937 × 7.087 × 1.339 in.

What type of bearing is the NU220 ECP?

The SKF NU220 ECP is a cylindrical roller bearing.

Is this a genuine SKF bearing?

Yes. Apollo Industries sells genuine SKF products, purchased through independent channels. Apollo is not an authorized distributor, reseller, or representative of SKF.

Do you ship the NU220 ECP the same day?

In-stock orders placed by 3 PM EST ship the same day. All orders over $100 ship free by ground with code FREESHIP.

Can I get quantity pricing or buy tax-exempt?

Yes. Apollo offers special rates for businesses and bulk orders. Use Request a quote on this page or call (248) 429-9073.
