Timken 22314 EMW33W800C4 Spherical Roller Bearing - 70 mm ID, 150 mm OD, 51 mm Width, Straight Bore, Open, C4
Brand:
Timken (Fafnir)
- Regular price
- $890.00
- Sale price
- $890.00
- Regular price
-
Shipping calculated at checkout.
5 in Stock Now
Free shipping on orders over $100
Use code at checkout.
FREESHIP
Orders placed before 3:00pm (Est) ship same day
Lightning-fast shipping, guaranteed.
Need Help?
Call us 1 (248) 429-9073
Description
(W33) Standard lubrication holes and groove in outer ring |(W800) Bearing has shaker screen modifications: Outer ring has reduced outside diameter tolerance, Inner ring has reduced bore tolerance, and Radial Internal Clearance in upper 2/3 of clearance specified
| Category | Property | Specification |
|---|---|---|
| Application | Application | Vibratory Applications |
| General | Type of Bearing | Spherical Roller Bearings |
| Product Type | Spherical Roller Bearings | |
| Manufacturer UPC Number | 087796026297 | |
| Dimensions | Bore Diameter | 70 mm |
| Outside Diameter | 150 mm | |
| Overall Width | 51 mm | |
| Bearing Components | Bearing Material | Steel |
| Element Material | Roller | |
| Cage | Cage Material | Brass |
| Cage Type | Machined | |
| Bore | Bore Type | Straight |
| Fillet Radius | 2.00 mm | |
| Closure | Closure Type | Open |
| Outer Ring Type | Not Split | |
| Internal Clearance | C4 | |
| Finish | Finish/Coating | Uncoated |
| Lubrication | Lubrication Hole Type | Lubrication Groove & Hole |
| Relubricatable | Yes | |
| Performance | Max RPM | 4,200 RPM |
| Precision | Precision Rating | Not Rated |
| Temperature | Operating Temperature Range | -65 to +392 °F |
| Series | Series | 223 |
| Weight | Weight | 9.52 lbs |
