About
Description
Product features
-
Optional WCB1 - T0053118299 programming module provides temperature lock-out, set back, ° F to ° C conversion, factory reset functions
-
Requires clean, filtered compressed air supply of 58 - 87 PSI
Technical Data
| Attribute | Details |
|---|---|
| Dimensions (L x W x H) | 175.0 x 135.0 x 102.0 mm |
| Air Consumption | 10 l/min |
| Capacity (l/min) | 10 l/min |
| Compressed Air Connection (Outer Diameter) | 0.23 in |
| Compressed Air Connection Accessory | Oil-free, dry compressed air |
| Compressed Air Supply (kPa/bar) | 400 kPa / 4 bar |
| Equipotential Bonding Socket | Via 3.5mm Jack Bush (Initial State-Hard-Grounded) |
| Fuse | T10A |
| Hot Air | Yes |
| Inert Gas Function | The inlet pressure is set permanently to 200 kPa by a pressure regulator. The pressure regulator must not be adjusted. |
| Maximum Hot Air Flow Rate (l/min) | 0 - 10 l/min |
| Number of Channels | 1 |
| Operating Pressure | 4 bar / 58 psi |
| Power | 105 W |
| Temperature Accuracy (°C) | ±9 °C (±30 °C) |
| Temperature Accuracy (°F) | ±17 °F (±50 °F) |
| Temperature Range (°C) | 50 - 450 °C (550 °C) |
| Temperature Range (°F) | 122 - 842 °F (999 °F) |
| Temperature Stability (°C) | ±2 °C |
| Temperature Stability (°F) | ±5 °F |
| UPC | 037103304100 |
| Voltage | 120 V/60 Hz |
Description
Product features
-
Optional WCB1 - T0053118299 programming module provides temperature lock-out, set back, ° F to ° C conversion, factory reset functions
-
Requires clean, filtered compressed air supply of 58 - 87 PSI
Technical Data
| Attribute | Details |
|---|---|
| Dimensions (L x W x H) | 175.0 x 135.0 x 102.0 mm |
| Air Consumption | 10 l/min |
| Capacity (l/min) | 10 l/min |
| Compressed Air Connection (Outer Diameter) | 0.23 in |
| Compressed Air Connection Accessory | Oil-free, dry compressed air |
| Compressed Air Supply (kPa/bar) | 400 kPa / 4 bar |
| Equipotential Bonding Socket | Via 3.5mm Jack Bush (Initial State-Hard-Grounded) |
| Fuse | T10A |
| Hot Air | Yes |
| Inert Gas Function | The inlet pressure is set permanently to 200 kPa by a pressure regulator. The pressure regulator must not be adjusted. |
| Maximum Hot Air Flow Rate (l/min) | 0 - 10 l/min |
| Number of Channels | 1 |
| Operating Pressure | 4 bar / 58 psi |
| Power | 105 W |
| Temperature Accuracy (°C) | ±9 °C (±30 °C) |
| Temperature Accuracy (°F) | ±17 °F (±50 °F) |
| Temperature Range (°C) | 50 - 450 °C (550 °C) |
| Temperature Range (°F) | 122 - 842 °F (999 °F) |
| Temperature Stability (°C) | ±2 °C |
| Temperature Stability (°F) | ±5 °F |
| UPC | 037103304100 |
| Voltage | 120 V/60 Hz |
Weller
by
Weller
Weller WAD101N Hot air station, 1 channel 120 V / 60 Hz Soldering Station
- Regular price
- $695.00
- Sale price
- $695.00
- Regular price
-
10 in Stock Now
Orders placed before 3:00pm (Est) ship same day
Lightning-fast shipping, guaranteed.
Free 90-day returns
Shop risk-free with easy returns.
Need Help?
Call us 1 (248) 429-9073
