NSK NU2313 W Cylindrical Roller Bearing - 65 mm ID, 140 mm OD, 48 mm Width, Cylindrical Bore, Normal
Brand:
NSK
- Regular price
- $281.91
- Sale price
- $281.91
- Regular price
-
Shipping calculated at checkout.
2 in Stock Now
Free shipping on orders over $100
Use code at checkout.
FREESHIP
Oxford, Michigan
FREE SHIPPING
All Orders Over $100 Ship Free Ground
EXPERT SUPPORT
Support Staff Available By Phone, Web Chat, Or Email.
PRICE MATCH
Simply provide proof of a competitor's advertised price on the same item, and we'll match it.
Full policy$610.00
$1,200.00
SS - Product Addons
Select product(s) to see addons appear.
This message only appears in theme editor.
Description
Cylindrical Roller Bearing
Cylindrical Roller Bearings have high radial load carrying capacity and are suitable for high speeds. The bearings are separable which facilitates mounting and dismounting. Manufactured to precision tolerance class for demanding applications. Robust steel cage construction ensures durability. Suitable for use in a wide range of industrial applications where reliability and performance are essential.
Key Features
- High radial load capacity
- High load carrying capacity
- Open design for flexibility
- Robust steel cage construction
- Wide temperature range operation
- Precision tolerance class
Specifications
Dimensions
| Bore Diameter | 65 mm |
| Outside Diameter | 140 mm |
| Width | 48 mm |
Properties
| Bore | Cylindrical bore |
| Cage | Sheet steel cage |
| Clearance | Normal radial clearance |
| Current insulation | No current insulation |
| Design | Floating bearing, inner ring removable on both sides |
| Outer ring | Without groove/lubrication holes |
| Roller rows | Single row bearing |
| Seal | None, open bearing |
| Temperature range | -30 to +150 °C |
| Tolerance class | Tolerance class P0/PN2 / ABEC 1 |
Logistics
| Product Net Weight | 3.27 |
How to Read an NSK Bearing Number
Every NSK bearing part number is built from a prefix (optional — load rating or special feature), a basic number (bearing type, dimension series, and bore size), and one or more suffixes (seals, clearance, cage, grease, and other features). Multiply the last two digits of the basic number by 5 to get the bore diameter in millimeters. Special bore codes: 00 = 10mm, 01 = 12mm, 02 = 15mm, 03 = 17mm.
6205 DDUCCM NS7S
6205 Deep groove ball, 62 series, 25mm bore • DDU Rubber seals both sides • CM Motor clearance • NS7 Hi-Lube grease • S Standard fill
HR 30207 J
HR Higher load rating • 302 Tapered roller series • 07 35mm bore • J Conforms to ISO 355
Prefixes & Type Codes
Bearing Type Codes (First Digit)
| Code | Bearing Type |
|---|---|
| 0 | Double row angular contact ball bearing |
| 1 | Self-aligning ball bearing |
| 2 | Spherical roller bearing / Self-aligning roller bearing |
| 3 | Tapered roller bearing |
| 4 | Double row deep groove ball bearing |
| 5 | Thrust ball bearing |
| 6 | Single row deep groove ball bearing |
| 7 | Single row angular contact ball bearing |
| 8 | Cylindrical roller thrust bearing |
Deep Groove Ball Bearing Series
| Series | Description |
|---|---|
| 60xx | Light series |
| 62xx | Medium series |
| 63xx | Heavy series |
| 64xx | Heavy series |
| 68xx | Extra-thin section series |
| 69xx | Thin section series |
Cylindrical Roller Bearings
| Prefix | Configuration |
|---|---|
| N | Double flanged inner ring, open outer ring |
| NF | Double flanged inner ring, single flanged outer ring |
| NU | Double flanged outer ring, open inner ring |
| NJ | Single flanged inner ring, double flanged outer ring |
| NUP | Double flanged outer ring, single flanged inner ring + loose rib |
| NH | Two-piece inner ring, double flanged outer ring |
| NN / NNU | Double-row cylindrical roller bearings |
Super Precision / Machine Tool Series
| Code | Description |
|---|---|
| BNR | Ultra high-speed angular contact, 18° contact angle |
| BER | Ultra high-speed angular contact, 25° contact angle |
| BSR | Ultra high-speed angular contact, 15° contact angle |
| BAR | High rigidity thrust angular contact, 30° contact angle |
| BTR | High rigidity thrust angular contact, 40° contact angle |
| TAC | Thrust angular contact for ball screw support |
Needle Roller Bearings
| Series | Description |
|---|---|
| NA48xx | Needle roller bearing with inner ring |
| NA49xx | Needle roller bearing with inner ring |
| NA59xx | Needle roller bearing with inner ring |
| NA69xx | Needle roller bearing with inner ring |
| RNA | Needle roller bearing without inner ring |
Bearing Unit Designations
| Code | Description |
|---|---|
| UC | Standard bearing insert |
| UK | Bearing insert with tapered bore |
| UCF | 4-bolt flange unit |
| UCFC | Piloted flange unit |
| UCP / SP | Standard pillow block unit |
| UCFL / SFT | 2-bolt flange unit |
| UCHT | Take-up unit |
Prefixes
| Prefix | Meaning |
|---|---|
| HR | Higher load rating (tapered roller and deep groove) |
| B | Non-standard boundary dimensions |
| F | Flanged outer ring |
| MR | Miniature metric bearing, special dimensions |
| MF | Miniature metric bearing, flanged outer ring |
| R | Outer ring with rollers and cage (no inner ring) |
| L | Outer ring of a separable bearing |
Suffixes
Seals & Shields
| Suffix | Meaning |
|---|---|
| Z | Steel shield (dust cover) on one side |
| ZZ | Steel shields on both sides |
| DU | Contact rubber seal on one side |
| DDU | Contact rubber seals on both sides |
| V | Non-contact rubber seal on one side |
| VV | Non-contact rubber seals on both sides |
| DD | Contact rubber seals on both sides (alternate code) |
| RR | OD riding trash guard rubber contact seals |
| RS | Face riding rubber contact seal |
| T | Face riding trash guard rubber contact seal |
| TT | Two face riding trash guard rubber contact seals |
| W | Two labyrinth seals |
Internal Clearance
| Suffix | Meaning |
|---|---|
| C1 | Clearance smaller than C2 (tightest) |
| C2 | Clearance less than Normal |
| CN | Normal clearance (default — usually not stated) |
| C3 | Clearance greater than Normal |
| C4 | Clearance greater than C3 |
| C5 | Clearance greater than C4 (loosest) |
| CM | Electric motor clearance (deep groove and cylindrical roller) |
| CT | Electric motor clearance (cylindrical roller) |
| MC3 | Normal clearance (miniature bearings) |
| MC5 | Larger than MC4 clearance (miniature bearings) |
Cage / Retainer Type
| Suffix | Meaning |
|---|---|
| M | Machined brass (copper alloy) solid cage |
| W | Pressed (stamped) steel cage |
| T | Synthetic resin (plastic) cage |
| J | Pressed steel retainer, two-piece ribbon type |
| Y | Pressed brass retainer, two-piece ribbon type |
| V | Full complement (no cage) |
| TYN | Polyamide resin cage, rolling element guided (~120 °C limit) |
| TR | Outer ring guided phenolic resin cage (~120 °C limit) |
| TB | PPS (polyphenylene sulfide) resin cage |
| TP | PEEK cage — for clean/vacuum environments |
| TS | Outer ring guided PEEK cage |
| MY | Rolling element guided brass cage |
Internal Design
| Suffix | Meaning |
|---|---|
| A | Non-standard internal design / internal redesign |
| J | Conforms to ISO 355 (tapered roller bearings) |
| C | High-capacity design (spherical roller) / 15° contact angle (angular contact) |
| CA | High-capacity spherical roller, copper alloy machined cage |
| EA | High-capacity spherical roller, stamped cage (high load) |
| E | High-load design (cylindrical roller / thrust roller) |
| EM | Cylindrical roller, copper alloy machined cage |
| ET | Cylindrical roller, polyamide molded cage |
| H | High-load design (thrust self-aligning roller) |
Contact Angle (Angular Contact)
| Suffix | Contact Angle |
|---|---|
| C | 15 degrees |
| A5 | 25 degrees |
| A | 30 degrees (standard) |
| B | 40 degrees |
Snap Ring, Bore & External Design
| Suffix | Meaning |
|---|---|
| K | Tapered bore, taper 1:12 |
| K30 | Tapered bore, taper 1:30 |
| N | Snap ring groove in outer ring |
| NR | Snap ring groove with snap ring installed |
| E4 | Outer ring with oil groove and 4 oil holes |
| X | Redesigned boundary dimension |
Tolerance / Precision Class
| Suffix | Meaning |
|---|---|
| P0 | Normal tolerance — ISO Class 0 (default, usually not stated) |
| P6 | ISO Class 6 (ABEC-3) |
| P5 | ISO Class 5 (ABEC-5) |
| P4 | ISO Class 4 (ABEC-7) |
| P2 | ISO Class 2 (highest standard precision) |
Preload (Angular Contact)
| Suffix | Meaning |
|---|---|
| EL | Extra light (micro) preload |
| L | Light preload |
| M | Medium preload |
| H | Heavy preload |
Matched Bearing Sets
| Suffix | Meaning |
|---|---|
| DB | Back-to-back (duplex) paired |
| DF | Face-to-face (duplex) paired |
| DT | Tandem (duplex) paired |
| DBB | Back-to-back four-column combination |
| SU | Single-column universal combination |
Heat Stabilization
| Suffix | Max Operating Temperature |
|---|---|
| X26 | Below 150 °C (300 °F) |
| X28 | Below 200 °C (390 °F) |
| X29 | Below 250 °C (480 °F) |
| S11 | Below 200 °C (spherical roller bearings) |
Material
| Suffix | Meaning |
|---|---|
| g | Carburized (case-hardened) steel rings and rolling elements |
| h / H | Stainless steel rings and rolling elements |
| H (precision) | Steel rings with ceramic (Si3N4) balls — hybrid bearing |
| X (precision) | High-speed heat-resistant steel with ceramic balls |
Grease / Lubrication
| Suffix | Description |
|---|---|
| NS7 | NS Hi-Lube — ester oil grease, −40 to +130 °C |
| AS2 | Shell Alvania S2 — lithium/mineral, high-load applications |
| LG2 | Lithium grease, clean environments, −20 to +70 °C |
| LGU | Urea grease, clean conditions |
| PS2 | Multemp PS No. 2 |
| ENS | ENS grease |
Grease fill: K ~20% • L ~20-30% • S ~30-55% (standard) • M ~55-70%
Need help choosing the right NSK bearing? Call us at 1 (248) 429‑9073 or use the chat below.
