BHT / BMT Series BEARHUG Locknuts – All-Metal, High Temperature

BHT (inch) and BMT (metric) are the all-metal BEARHUG locknuts. The polymer locking ring is replaced by an all-hardened-alloy prevailing-torque design, which lifts the maximum operating temperature from 160°F to 300°F. Use them wherever a standard BEARHUG nut would sit too close to a heat source for the polymer ring to survive.

BHT / BMT Series Specifications

• Part numbers: BHT-02 through BHT-14; BMT-02 through BMT-14 (26 sizes stocked)
• Bore / shaft size (inch): 0.586 in to 2.751 in
• Outside diameter (inch): 1 in to 3.625 in
• Bore / shaft size (metric): 15 mm to 70 mm
• Outside diameter (metric): 25 mm to 92 mm
• Material & temperature: All-metal hardened alloy steel, no polymer element; 300°F maximum operating temperature
• Standards: BHT to ANSI/ABMA 8.2-1999, BMT to ISO 2982-2:2013(E); made in USA

Applications

Kiln and oven drives, hot rolling and casting lines, turbine and engine accessories, dryer sections and any bearing running above the polymer limit.

Related Whittet-Higgins Series

• BH Series BEARHUG Locknuts – Inch
• BM Series BEARHUG Locknuts – Metric
• TLN / TLM Series TANGENTLOK Locknuts
• BL / BLM Series BEARLOK Locknuts
• HTW Series Hardened Tongued Washers

Apollo is an authorized Whittet-Higgins distributor. Every part on this page is genuine Whittet-Higgins, manufactured in the USA. Need a size that is not listed, or help matching a locknut to its lockwasher and assembly socket? Contact our team.
