Nachi 6004 -2NSE9C3 Deep Groove Ball Bearing - 20 mm ID, 42 mm OD, 12 mm Width, C3
Nachi 6004 -2NSE9C3 Deep Groove Ball Bearing - 20 mm ID, 42 mm OD, 12 mm Width, C3
- d 20 mm
- D 42 mm
- B 12 mm
- C3 - Loose
Brand:
Nachi
Genuine Nachi product, Nachi
- Regular price
- $20.30
- Sale price
- $20.30
- Regular price
-
Shipping calculated at checkout.
Call 1 (248) 429-9073 for Availability
Free shipping on orders over $100
Use code at checkout.
Why Apollo USA
Bearings from Apollo Industries, Oxford, Michigan
Apollo Industries supplies bearings, seals and maintenance tools to businesses across the US, with real people on the phone when you need a part matched.
-
Same-day shipping
Order by 3 PM EST for same-day shipping.
-
Free shipping over $100
All orders over $100 ship free by ground with code FREESHIP.
-
90-day returns
Hassle-free returns on unused items within 90 days.
-
Price match
Show us a competitor's advertised price on the same item and we will match it.
-
Expert support
Support staff available by phone, web chat or email.
-
Need tax exemption or quantity pricing?
We offer special rates for businesses and bulk orders.
Talk to a bearing specialist
2695 Lake George RdOxford, MI 48370
Overview
Nachi 6004-2NSE9C3 Deep groove ball bearing
Deep Groove Ball Bearing with contact seals on both sides and increased clearance
The Nachi 6004 -2NSE9C3 pairs a 20 mm bore with a 42 mm outside diameter and 12 mm width. Rubber contact seals ride on the inner ring land at both sides, giving a far tighter barrier against water, dust and washdown than a shield can manage, at the cost of a little more running torque. The grease is sealed in for the life of the bearing. C3 clearance offsets the fit-up and thermal losses that would otherwise leave the bearing preloaded, the cage is sheet steel, and the assembly is rated from -20 to +130 degrees C. Well suited to dirty or damp duty where relubrication is impractical.
Key features
- Contact seals both sides for wet and dusty duty
- Sealed grease fill, maintenance free
- Increased C3 clearance for thermal expansion
- Strong protection against washdown and airborne dirt
- Pressed sheet steel cage
- Operating range -20 to +130 degrees C
Specifications
Nachi 6004-2NSE9C3 dimensions & specifications
- Bearing type
- Deep groove ball bearing
- Bore diameter d
- 20 mm (0.787 in)
- Outside diameter D
- 42 mm (1.654 in)
- Width B
- 12 mm (0.472 in)
- Internal clearance
- C3 - Loose
- Weight
- 0.15 lb
- Brand
- Nachi
- Part number
- 6004-2NSE9C3 also written 60042NSE9C3
- UPC / EAN
- 4991893530179
All specifications
Dimensions
| Bore Diameter | 20 mm |
| Outside Diameter | 42 mm |
| Width | 12 mm |
Properties
| Ball rows | Single row bearing |
| Bore | Cylindrical bore |
| Cage | Sheet steel cage |
| Clearance | Slightly increased radial clearance |
| Current insulation | No current insulation |
| Material | Standard bearing steel |
| Material of rolling elements | Standard bearing steel |
| Outer ring | Without flange/groove |
| Seal | Contact seal on both sides |
| Temperature range | -20 to +130 °C |
| Tolerance class | Tolerance class P0/PN2 / ABEC 1 |
Logistics
| Product Net Weight | 0.07 |
Cross reference
6004-2NSE9C3 cross reference & equivalents
Bearings from other brands with the same boundary dimensions. Check seals, clearance, cage and precision class before you order.
-
FAG
6004-C-2HRS-C3 (-2RSR-C3)FAG 6004-C-2HRS-C3 (-2RSR-C3) Deep Groove Ball Bearing - 20 mm ID, 42 mm OD, 12 mm Width
- Same size
- Same clearance
$8.86
In stock
-
NSK
6004 DDUC3NSK 6004 DDUC3 Deep Groove Ball Bearing - 20 mm ID, 42 mm OD, 12 mm Width, Cylindrical Bore, C3
- Same size
- Same clearance
$9.04
In stock
-
Timken
6004-2RS-C3Timken 6004-2RS-C3 Single Row Deep Groove Ball Bearing, Metric Series, 20.0mm Bore, 42.0mm OD, 12.0mm Width, Double Sealed, Cylindrical Bore, Steel Cage, C3 Clearance, ISO P0 Tolerance
- Same size
- Same clearance
$15.68
Call for availability -
JTEKT-KOYO
6004-2RSC3JTEKT-KOYO 6004-2RSC3 Deep Groove Ball Bearing - 20 mm ID, 42 mm OD, 12 mm Width
- Same size
- Same clearance
$23.57
In stock
-
SKF
6004-2RS1/C3
Contact seals both sides, C3 clearance
-
NTN
6004LLUC3
Contact seals both sides, C3 clearance
Reference data only. Verify specifications before you order.
Search more equivalents in the Apollo Bearing IndexTools & lubrication
Complete the job for your 6004-2NSE9C3
Mount it without damage and keep it lubricated. Tick what you need and add it with one click.
Part number decoded
What every part of 6004-2NSE9C3 means
- 60
- 60xx extra-light deep groove ball (dimension series 10)
- 04
- Bore code 04 × 5 = 20 mm (ISO convention)
- 2NSE9
- Contact rubber seals, both sides (the lip touches the inner ring); the 9 is used on 10 to 50 mm bores
- C3
- Radial internal clearance greater than normal (CN)
Catalogs & documents
Nachi 6004-2NSE9C3 catalogs & documents
Official catalogs and data from the manufacturer. They open as PDFs in a new tab.
-
Catalog
Nachi Ball & Roller Bearings (B2100E-4) (opens in a new tab)
PDF · English
-
Catalog
Nachi Deep-groove Ball Bearings, QUEST (B3402E-2) (opens in a new tab)
PDF · English
-
Catalog
Nachi Spherical Roller Bearings (B1032E-5) (opens in a new tab)
PDF · English
-
Catalog
Nachi Radial Ball Bearings (B4031E-2) (opens in a new tab)
PDF · English
About the brand
About Nachi
Nachi-Fujikoshi, founded in Toyama, Japan, in 1928.
Nachi-Fujikoshi was founded on 21 December 1928 in Toyama City, Japan, as Fujikoshi Steel Industry. It makes bearings alongside cutting tools, hydraulics, robots and specialty steel. Its North American headquarters is in Greenwood, Indiana.
Genuine Nachi product
Founded
1928
Headquarters
Toyama, Japan
Known for
- Deep groove ball bearings (QUEST)
- Spherical roller bearings
- Precision bearings
- Ball screw support bearings
Disclaimer: Apollo Industries is not an authorized distributor, reseller, or representative of Nachi. All Nachi trademarks and product names are the property of their respective owners. We sell genuine Nachi products purchased through independent channels.
FAQ
6004-2NSE9C3 questions & answers
What are the dimensions of the Nachi 6004-2NSE9C3?
The Nachi 6004-2NSE9C3 has a 20 mm bore (d), a 42 mm outside diameter (D) and a 12 mm width (B). In inches: 0.787 × 1.654 × 0.472 in.
What type of bearing is the 6004-2NSE9C3?
The Nachi 6004-2NSE9C3 is a deep groove ball bearing.
What internal clearance does the 6004-2NSE9C3 have?
The Nachi 6004-2NSE9C3 has C3 - Loose internal clearance.
What can I use instead of the Nachi 6004-2NSE9C3?
Equivalents with the same boundary dimensions include FAG 6004-C-2HRS-C3 (-2RSR-C3), NSK 6004 DDUC3, Timken 6004-2RS-C3, JTEKT-KOYO 6004-2RSC3, SKF 6004-2RS1/C3, NTN 6004LLUC3. Check the seals, internal clearance, cage and precision class before you order.
Is this a genuine Nachi bearing?
Yes. Apollo Industries sells genuine Nachi products, purchased through independent channels. Apollo is not an authorized distributor, reseller, or representative of Nachi.
Do you ship the 6004-2NSE9C3 the same day?
In-stock orders placed by 3 PM EST ship the same day. All orders over $100 ship free by ground with code FREESHIP.
Can I get quantity pricing or buy tax-exempt?
Yes. Apollo offers special rates for businesses and bulk orders. Use Request a quote on this page or call (248) 429-9073.
