RN / ARN Series Bearing Removal Nuts

A removal nut threads onto the oversized end of a tapered adapter or withdrawal sleeve and pushes the bearing inner ring off the taper. RN nuts carry a UNS Special External Class 3A thread to ANSI/ABMA 8.2-1999, with a spanner-slotted face for driving and a flat pilot face that bears squarely on the bearing inner ring. ARN sizes thread onto the same shaft threads as the corresponding AN retaining nuts.

RN / ARN Series Specifications

• Part numbers: RN-10 through RN-38; ARN-22 through ARN-26 (11 sizes stocked)
• Bore / shaft size: 2.204 in to 8.191 in
• Outside diameter: 3.062 in to 10.688 in
• Material & temperature: Steel, spanner-slotted face with flat pilot diameter
• Standards: UNS Special External Class 3A thread per ANSI/ABMA 8.2-1999; made in USA. ARN outer dimensions should be confirmed with Whittet-Higgins before specifying — the designation is not in the published handbook.

Applications

Dismounting tapered-bore bearings from adapter and withdrawal sleeves during bearing replacement and shaft service.

Related Whittet-Higgins Series

• SNW Series Bearing Adapter Sets & Adapter Sleeve Assemblies
• HYAN / HYKM Series Hydraulic Installation Nuts
• N / AN Series Bearing Locknuts – Inch, SAE

Apollo is an authorized Whittet-Higgins distributor. Every part on this page is genuine Whittet-Higgins, manufactured in the USA. Need a size that is not listed, or help matching a locknut to its lockwasher and assembly socket? Contact our team.
