About
The FLIR VP50-2 is a durable, CAT IV-rated non-contact voltage detector featuring light, vibration, and beeper feedback alarms and a powerful LED flashlight. Use the VP50-2 to reliably check if an AC circuit is live before beginning work; detect voltage on exposed conducting parts or through insulation; identify live wires within electrical panels, switches, and outlets; or trace live wires and map circuits. With an ergonomic and drop-tested design, the FLIR VP50-2 is the right choice for professionals performing field troubleshooting and verification of electrical installations within residential, commercial, and industrial buildings.
| Category | Specification | Details |
|---|---|---|
| Specifications | Alarm Notification | Sound, Flashing LED, Vibration |
| Flashlight | Yes | |
| Tip Light | Yes | |
| Drop Test | 3 m (9.8 ft) | |
| Category Rating | CAT IV-1000 V | |
| Certifications | cULus | |
| Warranty | Limited 3-year | |
| Measurement & Analysis | AC Voltage Range | 90 to 1000 V AC (default, solid green light) |
| Category Rating | CAT IV-1000 V | |
| Frequency Range | 45 to 65 Hz | |
| High Sensitivity Mode | 24 to 1000 V AC (solid amber light) | |
| Vibrating Indication | Yes | |
| Environmental & Certifications | Ambient Temperature Range for Operation | -10 to 50°C (14 to 122°F) |
| Certifications | cULus | |
| Drop Test | 3 m (9.8 ft) | |
| Storage Temperature | -20 to 60°C (-4 to 140°F) | |
| Warranty | Limited 3-year | |
| General | Dimensions (L x W x H) | 158.5 x 26 × 29 mm (6.24 x 1.02 x 1.14 in) |
| Weight | 59 g (2.1 oz) including batteries | |
| Power | Battery Life | ~5 hours continuous (flashlight off) |
| Power Requirements | 2 × AAA alkaline batteries |
The FLIR VP50-2 is a durable, CAT IV-rated non-contact voltage detector featuring light, vibration, and beeper feedback alarms and a powerful LED flashlight. Use the VP50-2 to reliably check if an AC circuit is live before beginning work; detect voltage on exposed conducting parts or through insulation; identify live wires within electrical panels, switches, and outlets; or trace live wires and map circuits. With an ergonomic and drop-tested design, the FLIR VP50-2 is the right choice for professionals performing field troubleshooting and verification of electrical installations within residential, commercial, and industrial buildings.
| Category | Specification | Details |
|---|---|---|
| Specifications | Alarm Notification | Sound, Flashing LED, Vibration |
| Flashlight | Yes | |
| Tip Light | Yes | |
| Drop Test | 3 m (9.8 ft) | |
| Category Rating | CAT IV-1000 V | |
| Certifications | cULus | |
| Warranty | Limited 3-year | |
| Measurement & Analysis | AC Voltage Range | 90 to 1000 V AC (default, solid green light) |
| Category Rating | CAT IV-1000 V | |
| Frequency Range | 45 to 65 Hz | |
| High Sensitivity Mode | 24 to 1000 V AC (solid amber light) | |
| Vibrating Indication | Yes | |
| Environmental & Certifications | Ambient Temperature Range for Operation | -10 to 50°C (14 to 122°F) |
| Certifications | cULus | |
| Drop Test | 3 m (9.8 ft) | |
| Storage Temperature | -20 to 60°C (-4 to 140°F) | |
| Warranty | Limited 3-year | |
| General | Dimensions (L x W x H) | 158.5 x 26 × 29 mm (6.24 x 1.02 x 1.14 in) |
| Weight | 59 g (2.1 oz) including batteries | |
| Power | Battery Life | ~5 hours continuous (flashlight off) |
| Power Requirements | 2 × AAA alkaline batteries |
FLIR VP50-2 CAT IV Non-Contact Voltage Detector, Featuring Light, Vibration, and Beeper Feedback Alarms
